Snap-On BC5500B - Wiring Diagram

15
BC5500B Operating Instructions
Wiring Diagram
Figure 4: Wiring Diagram, BC5500B Super 550 Battery Charger
A – Fine Rate
B – Course Rate
C – Black
D – White
E – Yellow
F – Red
G – Blue
H – Green
I – Brown
J–Gray
SAVE THESE INSTRUCTIONS
