Operating Instructions EEBC300A
4. Slide wheel onto axle with hub toward charger, then slide
axle through charger base.
5. Place remaining wheel on axle and tap retainer nuts onto
axle.
Parts List
Description
Part Number
Rectifier Assembly ...................................... BC4200-2000R
Transformer Assembly ................................ EAT0004K00AR
Fan Blade ................................................................ 2-1268
Fan Motor ............................................................ 2-10166-1
DC Leads with Clamps .............................. EAX0023K00AR
DC Circuit Breaker .................................................. 2-15366
AC Circuit Breaker .................................................. 2-10266
Ammeter .................................................................... 4-280
Voltmeter .................................................................... 4-380
Power Cord .............................................................. 6-2821
Rotary Voltage Range Switch .................................. 2-13659
Standard/Fleet Voltage Range Switch ...................... 2-9958
Charge Timer .......................................................... 2-14866
Knob, Charge Timer or Voltage Range ...................... 8-8230
Handle with Hardware .................................. EAK0073K20A
Includes handle, crossbar and 6 screws
Foot with 4 screws ........................................ EAK0073K21A
Wheel Kit ...................................................... EAK0073K22A
Includes 2 wheels, 2 push nuts and axle
