8
Operating Instructions EEBC300A
A—Charging Mode Switch
Selects charging mode.
— Standard, 6 and 12 volt, and
— Fleet, 18 and 24 volt.
B—Standard Voltage Range Switch
Selects volts for charge when Charging Mode Switch indicates
Standard mode. Range settings are:
—6LO,
— 6HI,
—12LO, or
— 12HI.
C—Fleet Voltage Range Switch
Selects volts for charge when Charging Mode Switch indicates
Fleet mode. Range settings are:
—18LO,
— 18HI,
—24LO, or
— 24HI.
D—Voltmeter
Displays volts, 0 to 30 DC, flowing from charger into battery.
E—Length of Charge Timer
Selects charger power mode and charge duration with manual
or automatic shut-off functions.
• OFF electrically shuts off power to the charger.
— Select before connecting or disconnecting power cord or
any leads.
• HOLD powers charger until OFF is manually selected.
— Select when desired charge time exceeds 120 minutes.
Charger does not turn off automatically when this function
is selected.
• CHARGE TIME is number of minutes the charger operates
before automatically shut-off. Charger shuts off automatically
after number of minutes selected lapse when this function is
selected.
— Up to 120 minutes can be selected. Increase or
decrease charge time as needed by selecting new time.
✓✓
✓✓
The charger automatically shuts off when the charge
time reaches zero.
F—Ammeter Meter
Displays amps, 0 to 100 DC, flowing from charger into battery.
