Snap-On VERSATORQ 2 SYSTEM User Manual

Specifications
Sensor Ranges / (Resolutions) in Different Units of Torque Measurements
*Knurled handles allows for fingertip control.
**Diameter does not include side mounted connector
***Heavy duty coiled cord with four-pin MS style connector.
Part Number
Range
ft-lb
in-lb
In-oz
Nm
cNm
Kg
cmKg
VERSA1S20A*
2-20 oz-in
0.011-0.104
(.001)
0.125-1.250
(.001)
02.00-20.00
(.01)
0.014-0.141
(.001)
01.42-14.12
(.01)
0.002-0.014
(.001)
0.145-1.440
(.001)
VERSA1S10A*
1-10 in-lb
0.084-0.833
(.001)
01.00-10.00
(.01)
16.00-160.0
(.01) (.1)
0.110-1.130
(.001)
011.3-112.9
(.01)
0.012-0.115
(.001)
01.16-11.52
(.01)
VERSA1S50A
5-50 in-lb
0.417-4.167
(.001)
05.00-50.00
(.01)
080.0-800.0
(.1)
0.565-5.649
(.001)
056.5-564.9
(.1)
0.058-0.576
(.001)
05.77-57.61
(.01)
VERSA1S200A
20-200 in-lb
01.67-16.66
(.01)
020.0-200.0
(.1)
0320-3200
(1)
02.26-22.59
(.01)
0223-2259
(1)
0.231-2.305
(.001)
023.1-230.4
(.1)
VERSA2S100A
10-100 ft-lb
010.0-100.0
(.1)
0120-1200
(1)
N/A
013.6-135.5
(.1)
N/A
01.39-1.82
(.01)
0139-1382
(1)
VERSA3S250A
25-250 ft-lb
025.0-250.0
(.1)
0300-3000
(1)
N/A
033.9-339.0
(.1)
N/A
03.46-34.66
(.01)
0346-3456
(1)
VERSA4S600A
60-600 ft-lb
060.0-600.0
(.1)
0720-7200
(1)
N/A
081.3-813.4
(.1)
N/A
08.30-82.97
(.01)
0830-8295
(1)
VERSA5S1500A
**
***
150-1500 ft-lb
0150-1500
(1)
N/A
N/A
0203-2034
(1)
020.8-207.4
(.1)
N/A
Display . . . . . . . . . 4 Digit w/Alpha & Numerical Function Flags
Display Capacity* . . . . . . . . . . . . . . . . . 4 Digits
9 pin maximum sensor connector Um Voltage Value. . . . 20 volts
Accuracy. . ±1% of Reading (10 to 100% of Sensor Range)
. . ±2% with VERSA1S10A and VERSA1S20A Sensors
Push Button Key Pad . . . . . . . . . . ZERO TARE, ON/OFF, SET UP,
UNITS, STORE, RECALL, CLEAR, SEND, ENTER, UP/DOWN/SIDE
Units of Measurement . . . . . . . . . . . . . . . . . . ft-lb, in-lb, in-oz,
Nm, cNm, mKg and cmKg
Operating Temperature . . . . . . . . . . 23 to 42ºC (40 to 110ºF)
Storage . . . . . . . . . . . . . . . . . . . . . . -20 to 50ºC (-2 to 122ºF)
Humidity . . . . . . . . . . . . . . . . . . . Up to 90%, Non-condensing
Dimensions . . . . . . . . . . . . . . . . . . 3” Wide, 2.5” High, 6” Deep
(3” High with Belt Clip)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Pound
Charge Life (Full Charge to Shut-off) . . . 100 Hours Continuous
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 AA Alkaline
Manufacturer Part No.
Energizer…………… E91
Panasonic …………. LR6XWA
Duracell ……………. MN1500
ATEX / UL Certified. . . . . . . . . . . . . . . . DEMKO 16 ATEX 1699X
Hazardous Location Designation . . . . . Class 1, Zone 2, Ex ic IIA
Temperature Class . . . . . . . . . . . . . . . . . T6
File number . . . . . . . . . . . . . . . . . . . . . . . E484919
Data Storage/Recall . . . . . . . . . . . . . . . . 3,500 Measurements
* VERSATORQ®2 display ignores torque inputs less than 0.5% of
full scale in Track mode and 2.0% of full scale in Peak mode.
VERSATORQ®2 Sensors provide industry standard square drives.
They feature a full bridge strain-gage @ 350 Ohms nominal.
Sensors use a built-in EEPROM memory chip that stores sensor
identification and calibration factors. Once a sensor is calibrated, it
retains its accuracy between all VERSATORQ®2 Meters.
User calibration of sensors is possible given a known input torque
and the VERSATORQ®2 torque analyzer Set-up function. Refer to
page 12 for Calibration Procedures.
Sensors can withstand an overload of 120% of full range. The
VERSATORQ®2 torque analyzer will alarm, (audible beep and
display “OVER” flag) at 120 % of rated capacity.
Range
Part No.
Drive
Diam.
Length
Cable
2-20 in-oz*
VERSA1S20A*
¼ in.
0.5 in
2.9 in
48 in.
1-10 in-lb*
VERSA1S10A*
¼ in.
0.7 in
2.9 in
48 in.
5-50 in-lb
VERSA1S50A
¼ in.
0.9 in
2.1 in
48 in.
20-200 in-lb
VERSA1S200A
¼ in.
0.9 in.
2.1 in.
48 in.
10-100 ft-lb
VERSA2S100A
3/8 in.
1.2 in.
2.4 in.
48 in.
25-250 ft-lb
VERSA3S250A
½ in.
1.4 in.
2.6 in.
48 in.
60-600 ft-lb
VERSA4S600A
¾ in.
2.0 in.
3.9 in.
96 in.
150-1500 ft-lb
VERSA5S1500A**
1 in.
2.4 in.
4.4 in.
92 in.***
* Knurled Handle for Fingertip Control
** Diameter Does Not Include Side Mounted Connector
*** Heavy Duty Coiled Cord with 4 pin MS style Sensor Connector
Torque Analyzer
Sensors

Snap-On VERSATORQ 2 SYSTEM Specifications
