Snap-On YA212A User Manual

Snap-on Tools Corporation Kenosha, WI 53141-1410 WC5395 PAGE 11
FIGURE C
QTY.DESCRIPTION
PART
NO.
DIA.
MKGS.
ITEM
NO.
1 CB2 SN-519 BREAKER, MINI 5A ............................................................................................................................. 1
2 CR1 SN-276S RELAY, 8 PIN 24VAC .......................................................................................................................... 1
3 SN-276CL RELAY CLIP, 8 PIN ............................................................................................................................. 1
4 SN-500A BULKHEAD ASSEMBLY, FEMALE ..................................................................................................... 2
SN-501 BULKHEAD, MALE .............................................................................................................................. 2
SN-501K BULKHEAD KIT, COMPLETE ............................................................................................................. 2
SN-880 COVER, THREAD ............................................................................................................................... 1
5 SN-138C24A WIRE DRIVE ASSEMBLY (FIGURE C1) ............................................................................................ 1
6 SN-323 SPOOL BRACKET .............................................................................................................................. 1
7 SN-22 SPOOL CLIP ....................................................................................................................................... 1
8 SN-122 SPOOL HUB ASSEMBLY ................................................................................................................... 1
SN-15 SHAFT ................................................................................................................................................. 1
SN-16 BUSHING ............................................................................................................................................ 2
SN-18 TENSION SPRING .............................................................................................................................. 1
SN-19 WASHER, SPOOL HUB ..................................................................................................................... 3
9 SN-20B BOLT, TENSION ................................................................................................................................. 1
10 SN-120 BASE, 4" ADAPTER ............................................................................................................................ 1
11 SN-1055 LABEL, SELECTION ........................................................................................................................... 1

Snap-On YA212A Specifications

General

Power Factor	0.73
Type	MIG
Input Phase	Single-Phase
Input Frequency	60 Hz
Protection Class	IP21
