Snap-on Tools Corporation Kenosha, WI 53141-1410 WC5395 PAGE 5

FIGURE A

QTY.DESCRIPTION

*1 SN-407L COVER, LEFT *(MUST BE PURCHASED AS A COMPLETE ASSY) ................................................ 1

* SN-427 COVER & ACCESS DOOR ASSEMBLY, COMPLETE ....................................................................... 1

2 SN-330A KNOB, HEAT & TRIM .......................................................................................................................... 2

3 SN-319 HANGER, CABLE ............................................................................................................................... 2

4 V SN-115 VOLTMETER (ROUND CORNERS) ................................................................................................... 1

SN-115A VOLTMETER (SQUARE CORNERS) (SERIAL# 812I-19333 AND LATER) ....................................... 1

SN-115L LENS, VOLTMETER (ROUND CORNERS) ....................................................................................... 1

SN-115AL LENS, VOLTMETER (SQUARE CORNERS) ..................................................................................... 1

5 SN-306 SIDE, LEFT ......................................................................................................................................... 1

SN-1003 LABEL, SIDE ....................................................................................................................................... 2

6 CB1 SN-482 CIRCUIT BREAKER, 35 AMP ............................................................................................................. 1

SN-955 BREAKER BRACKET ......................................................................................................................... 1

7 SN-1101 LABEL, WELD CONNECTOR ............................................................................................................ 1

8 SN-124-8 REAR WHEEL, 8" ............................................................................................................................... 2

9 SN-05 HANDLE .............................................................................................................................................. 1

*10 SN-407R ACCESS DOOR *(MUST BE PURCHASED AS COMPLETE ASSY) ................................................ 1

11 SN-1053 LABEL, CONTROL .............................................................................................................................. 1

12 SN-308U FRONT, UPPER .................................................................................................................................. 1

13 SN-71 BUSHING ............................................................................................................................................ 1

14 L SN-184 INDICATOR LAMP .............................................................................................................................. 1

15 - SN-146 WELD CONNECTOR .......................................................................................................................... 1

SN-72 NUT, WELD CONNECTOR ................................................................................................................ 2

SN-178 GROUND CABLE ASSEMBLY, 15' (NOT SHOWN) ........................................................................... 1

SN-165 CLAMP, GROUND (NOT SHOWN) .................................................................................................... 1

16 + SN-146C WELD CONNECTOR W/GAS HOLE ................................................................................................. 1

17 SN-304 SIDE, RIGHT ....................................................................................................................................... 1

18 SN-302 BASE ................................................................................................................................................... 1

19 SN-171 AXLE .................................................................................................................................................... 1

SN-171C AXLE, CAPS ........................................................................................................................................ 2

SN-217W AXLE, WASHER ................................................................................................................................. 4

20 SN-308L FRONT, LOWER ................................................................................................................................. 1

21 SN-213 CASTER BRACKET ............................................................................................................................ 1

22 SN-121-3 CASTER, FRONT 3" ........................................................................................................................... 2

PART

NO.

DIA.

MKGS.

ITEM

NO.
