Snap-on Tools Corporation Kenosha, WI 53141-1410 WC5395 PAGE 7

FIGURE B

QTY.DESCRIPTION

1 SN-303A BACK (SERIAL# 812I-15581 TO 812I-18155) ..................................................................................... 1

SN-303F " REVISED (SERIAL# 812I-18156 AND LATER) ............................................................................... 1

2 GS SN-126B SOLENOID ASSEMBLY, 24VAC ........................................................................................................1

3 SN-253A GAS HOSE, PRIMARY ........................................................................................................................ 1

4 SN-211 CYLINDER BRACKET ........................................................................................................................ 1

5 SN-211C CYLINDER CHAIN .............................................................................................................................. 1

6 RC1 SN-173 PLUG, MOTOR BASE (SERIAL# 812I-15581 TO 812I-18155) ........................................................... 1

7 PLG1 20CP-1 POWER INPUT CABLE, 20' (SERIAL# 812I-15581 TO 812I-18155) .................................................. 1

" 20CP-0 " (SERIAL# 812I-18156 AND LATER) ................................................................................................. 1

SN-220 STRAIN RELIEF (SERIAL# 812I-18156 AND LATER) ........................................................................ 1

SN-220N NUT, STRAIN RELIEF (SERIAL# 812I-18156 AND LATER) .............................................................. 1

8 SN-305A BAFFLE (REVISED) ............................................................................................................................ 1

9 SN-353S GAS HOSE, SELECTOR .................................................................................................................... 1

10 SN-6421U BRACKET, CONTROL (U-BOARD) .................................................................................................... 1

11 SN-601 STAND OFF, NYLON BOARD ............................................................................................................ 4

12 PC1 SN-774U WIRE FEED CONTROL BOARD (FIGURE B1) ................................................................................. 1

13 SN-685 TERMINAL HOUSING, HARNESS ..................................................................................................... 1

SN-685P PIN, EDGE CONNECTOR .................................................................................................................. 6

14 RC4 SN-861C RECEPTACLE, FUNCTION ................................................................................................................ 1

15 SN-236 SOCKET, RELAY 8 PIN ...................................................................................................................... 1

16 SN-353D HOSE, BULKHEAD, (MIG FITTING) ................................................................................................... 1

17 R1 SN-35U POTENTIOMETER, 75K OHM ............................................................................................................ 1

18 S2 SN-163-12 HEAT SWITCH, 12 POSITION ........................................................................................................... 1

19 T2 SN-287M CONTROL TRANSFORMER, 230V-28V ............................................................................................ 1

20 SN-353E HOSE, BULKHEAD, (MHG5-A FITTING)............................................................................................ 1

21 W SN-153 CONTACTOR, 24VAC ........................................................................................................................ 1

22 D1,2,3,4 SN-260 DIODE ................................................................................................................................................. 4

23 SN-360 HEAT SINK ASSEMBLY, COMPLETE ............................................................................................... 1

24 R2 SN-162 RESISTOR, 100 OHM 25W ................................................................................................................ 1

25 SN-255M LEG, HEAT SINK ................................................................................................................................ 2

26 C1 SN-125S CAPACITOR, 12,000UF 50V ............................................................................................................... 6

27 T1 SN-286C TRANSFORMER, POWER ................................................................................................................. 1

TP1 SN-654 THERMAL SWITCH (N.C.) ................................................................................................................. 1

28 Z SN-188C CHOKE ................................................................................................................................................ 1

29 F SN-117 FAN MOTOR, SMALL ......................................................................................................................... 1

30 SN-318 FAN BLADE ......................................................................................................................................... 1

31 SN-310A FAN BRACKET W/SHROUD .............................................................................................................. 1

32 RC2 SN-172 MOTOR BASE (230V-20A) (SERIAL# 812I-15581 TO 812I-18155) .................................................... 1

PART

NO.

DIA.

MKGS.

ITEM

NO.
