GEARBOX, SHAFTS
ITEM PART NO. DESCRIPTION
1* 2-8220 SHAFT, Auger (8245 Models)
- 2-7639 SHAFT, Auger (8265 & 9265 Models)
- 2-9552 SHAFT, Auger (10305E, 11305 & E11305 Models)
2 1-3857 KEY, 1/4 x 7/8" Woodruff
3 5-1305 GEAR, Worm
4 1-3855 WASHER, 1.0 x 1-1/2" Thrust (2)
5 1-3858 SEAL, 1-1/2” O.D. Oil (2)
6 1-8451 COVER, Gear Case
7 9-0290 SCREW, 1/4-20 x 3/4" Hex Washer Self-Tap (4)
8 1-3854 O-RING, Case Cover
9 1-9674 CASE, Gear
10 9-0815 SCREW, 3/8-16 x 1/2" Hex Washer Self-Tap
11 2-7630 SHAFT, Impeller
12 1-3313 BEARING, Impeller Shaft
13 1-3862 PIN, 1/4 x 1-1/2" Roll
14 1-3856 SPACER, Gear Bearing
15 1-3861 KEY, 3/16 x 7/8" Woodruff
16 2-7606 GEAR, Rolled Worm
17 1-0935 WASHER, 3/4 x 1-1/8" Thrust (2)
18 1-2252 BUSHING, Impeller Shaft
19 1-3853 O-RING, Case Cap
20 1-8450 CAP, Case
21 9-1075 SCREW, #10-24 x 5/8" Hex Washer Self-Tap (3)
*NOTE: The following assemblies are made
of items 1 through 21 above:
5-3426, 24” Gear Case Assembly
5-7305, 26” Gear Case Assembly
5-7304, 30” Gear Case Assembly
LARGE FRAME SNOWTHROWER MANUAL No. 06037
