Snapper 10305E - Chain Case and Drive Components

14
CHAIN CASE (TRACTION DRIVE)
MANUAL No. 06037 LARGE FRAME SNOW THROWER
CHAIN CASE ASSEMBLY
HEX SHAFT
(See Item #15, Pages 12- 13
NOTE: USE “00” GREASE
FOR LUBRICATION
