ACCESSORIES
HARDWARE BAG KIT #6-1368 (for Model 8245)
PART NO. DESCRIPTION
9-1070 NUT, 5/16-18 Hex Flange Lock, Grade 5 (4)
1-6314 WASHER, 5/16 x 1-1/4" Flat (2)
1-3849 SPACER
3-2910 LEVER, Clutch
2-8223 CABLE, Auger/Cable (2)
9-1067 NUT, 5/16-18 Hex Center Lock. Grade B
9-1071 NUT, 3/8-16 Hex, Grade B
1-6304 NUT, 3/8-16 x 1-3/4" Connector
1-1938 RETAINER, Chute
9-1075 SCREW, #10-24 x 5/8" Hex Washer Self-Tap (2)
1-3865 BOLT, 5/16-18 x 5/8" Shear (2)
9-1298 NUT, 5/16-18 Hex Nyloc (2)
9-0041 PIN, 1/8 x 1” Cotter
9-1082 PIN, 3/32 x 3/4” Cotter
9-1550 BOLT, 5/16-18 x 1-7/8" Shear (2)
9-1149 WASHER, 3/8 Flat
HARDWARE BAG KIT #6-1366 (for Model 8265)
PART NO. DESCRIPTION
9-1070 NUT, 5/16-18 Hex Flange Lock, Grade 5 (8)
1-6314 WASHER, 5/16 x 1-1/4" Flat (2)
1-3849 SPACER
3-2910 LEVER, Clutch
9-1149 WASHER, 3/8 Flat
9-1067 NUT, 5/16-18 Hex Center Lock, Grade B
9-1071 NUT, 3/8-16 Hex, Grade B
1-6304 NUT, 3/8-16 x 1-3/4" Connector
1-1938 RETAINER, Chute
9-1075 SCREW, #10-24 x 5/8" Hex Washer Self-Tap (2)
9-1298 NUT, 5/16-18 Hex Nyloc (2)
9-0001 BOLT, 5/16-18 x 3/4" Short Neck Carriage
9-0187 WASHER, 5/16 Split Lock
9-0196 NUT, 5/16-18 Hex
9-0041 PIN, 1/8 x 1” Cotter
9-1082 PIN, 3/32 x 3/4” Cotter (2)
9-1550 BOLT, 5/16-18 x 1-7/8" Shear (2)
HARDWARE BAG KIT #6-1365
(for Models: E8265, 9265, E9265, 10305, 10305E, E10305, E10305E, 11305 and E11305)
PART NO. DESCRIPTION
9-1070 NUT, 5/16-18 Hex Flange Lock,
Grade 5 (4)
1-6314 WASHER, 5/16 x 1-1/4" Flat (2)
1-3849 SPACER
3-2910 LEVER, Clutch
9-0037 PIN, 3/32 x 3/4" Cotter (2)
9-1067 NUT, 5/16-18 Hex Center Lock,
Grade B
9-1071 NUT, 3/8-16 Hex, Grade B
1-6304 NUT, 3/8-16 x 1-3/4" Connector
1-1938 RETAINER, Chute
9-1075 SCREW, #10-24 x 5/8" Hex
Washer Self-Tap (2)
PART NO. DESCRIPTION
1-3865 BOLT, 5/16-18 x 5/8" Shear (2)
9-1298 NUT, 5/16-18 Hex Nyloc (2)
2-8223 CABLE, Auger/Clutch
9-0001 BOLT, 5/16-18 x 3/4" Short Neck
Carriage (2)
9-0187 WASHER, 5/16 Split Lock (2)
9-0196 NUT, 5/16-18 Hex (2)
9-0041 PIN, 1/8 x 1” Cotter
9-1082 PIN, 3/32 x 3/4” Cotter
9-1550 BOLT, 5/16-18 x 1-7/8" Shear (2)
1-2080 TIE, Cable 7” (2)
MANUAL No. 06037 LARGE FRAME SNOWTHROWER
