Snapper 150Z Series

Figure 28. Blade Installation - 42” Deck
A. 4x4 Wood Block C. Blade Nut
B. Spring Washers D. Lift Wings
A
B
C
D
21
Figure 27. Blade Installation - 33” Deck
A. Blade
B. Blade Mounting Bolts
C. Lockwashers
D. Hex Nuts
A
D
C
E
B
Figure 29. Blade Installation - 50” Deck
A. 4x4 Wood Block
B. Hex Washer
C. Spring Washer
D. Blade Capscrew
E. Lift Wings
B
D
C
A
