20
www.SnapperPro.com
Operation
Figure 8. Hydraulic System By-Pass
A. Hydraulic Bypass Valve
Pushing the Rider By Hand
NOTICE
Do NOT tow rider.
Towing the units will cause hydraulic
transmission damage. Do not use another
vehicle to push or pull this unit.
1. Disengage the PTO, engage the parking brake,
turn the ignition OFF, and remove the key.
2. Locate the bypass actuators (A, Figure 8) on
the side of the unit’s transmissions. There is one
bypass actuator on each transmission. The bypass
actuator opens and closes the transmission bypass
valves.
3. To open the transmission bypass valves rotate
the bypass actuator clockwise to the “bypass”
position” (marked “bypass” on the transmission)
(B).
4. Disengage the parking brake. The zero-turn rider
can now be pushed by hand.
5. After moving the zero-turn rider, close the bypass
valves by rotating the bypass actuator counter-
clockwise to the “run” position (marked “run” on
the transmission) (C).
Note: Both transmission release levers must be in the
same position.
BYPASS
RUN
BYPASS
RUN
A
B C
