52
ACCESSORY, SNOW BLADE SUPPORT 6-1370
(for 1-Piece Frame Hydro Drive Tractors)
ITEM PART NO. DESCRIPTION
-- 6-1370 KIT, Snow Blade Support (Includes all below in a box)
-- 5-3443 ASSEMBLY, Snow Blade Support (Includes indented items below)
1 4-1632 WELDMENT, Support Tube
2 2-8237 PLATE, Lower Pulley Support
3 9-1585 NUT, 3/8-16 Hex Center Lock, Grade 5 or B (4)
4 9-1305 SCREW, 3/8-16 x 2” Hex Head Cap, Grade 5 (4)
ACCESSORY, SNOW THROWER SUPPORT UPDATE KIT 6-1781
(for SERIES A & B 1-Piece Frame Hydro Drive Tractors)
MANUAL No. 06613 LT SERIES (Small Frame)
