SERVICE SCHEDULE
ITEM SERVICE PERFORMED
REF. EACH
USE
5
HRS
25
HRS
50
HRS
100
HRS
EACH
SEASON
Engine Oil
Check Oil Level Page 9
X
Initial Oil Change Page 13
X
Periodic Oil Change Page 13
X*
Air Pre-Cleaner
Clean Sponge Element Engine Manual
& Page 14
X**
Air Cleaner
Clean or Replace Engine Manual
X**
Spark Plug
Replace Engine Manual
X
Fuel Filter
Replace Page 16
X
Engine Cooling
System
Clean Shroud & Fins Engine Manual
& Page 15
X**
Battery
Check Electrolyte Page 23
X X
Charge Battery Page 22
X
Testing Battery Pages 23
X
Tires
Check Pressures Page 9
X X X
Drive Belts
Check For Wear And
Tension
Page 14
X X X
Mower Blades
Check For Wear, Damage
& Replacement
Pages 20-21
X
Mower Deck
Clean Debris
Accumulation
Page 14
X
Lubrication
Points
Grease or Oil Pages 14-15
X X
Hydrostatic
Trans. Oil
Check Oil Level Page 15
X X
Hydrostatic
Trans. Filter
Replace Filter Page 15 First Change at 200 Hours.
Thereafter every 500 Hours.
* Change oil every 25 hours when operating under heavy load or high temperatures.
**Clean more often under dusty conditions or when air debris is present
MAINTENANCE PARTS
5.9. MAINTENANCE/REPLACEMENT PARTS
MAINTENANCE/REPLACEMENT PARTS 52” MOWER DECK 61” MOWER DECK
Mower Blades – High Lift 2-9246 (3) 2-9251 (3)
Mower Blades – Low Lift 7-3395 (3) 7-3396 (3)
Mower Deck Belt 4-2776 3-5542
Upper Drive Shaft To Hydro Pump Belt 4-5254 (2)
Deck Drive Shaft To Electric Clutch -Belt 5-8209
Battery 3-5610
