Power Rating
The gross power rating for individual gas engine models is labeled in accordance with SAE (Society of Automotive Engineers)
code J1940 (Small Engine Power & Torque Rating Procedure), and rating performance has been obtained and corrected in
accordance with SAE J1995 (Revision 2002-05). Torque values are derived at 3060 RPM; horsepower values are derived
at 3600 RPM. Net power values are taken with exhaust and air cleaner installed whereas gross power values are collected
without these attachments. Actual gross engine power will be higher than net engine power and is affected by, among other
things, ambient operating conditions and engine-to-engine variability. Given the wide array of products on which engines
are placed, the gas engine may not develop the rated gross power when used in a given piece of power equipment. This dif-
ference is due to a variety of factors including, but not limited to, the variety of engine components (air cleaner, exhaust,
charging, cooling, carburetor, fuel pump, etc.), application limitations, ambient operating conditions (temperature, humidity,
altitude), and engine-to-engine variability. Due to manufacturing and capacity limitations, Briggs & Stratton may substitute an
engine of higher rated power for this Series engine.
Common Service Parts Part Number
Mower
Mower Blade 7103288YP
Drive Belt 7103664YP
Engine
Air Filter 795066, 5419
Air Filter Pre-Cleaner 796254
Resistor Spark Plug 692051
Fuel Filter 298090, 5018
Fuel Additive 5041, 5058
Specifications
Mower
Deck Size (in) 22
Height of Cut (in) 1.25 - 4
Transmission Type Variable Speed/Gear
Ground Speed (mph) 0 - 4.2
Blade Torque (ft-lbs) 40
Engine
Engine Power (ft-lbs) 8.75
Engine Displacement (cc) 190
Fuel Tank Capacity (qt) 1.2
Oil Capacity (oz) 18 - 20
Spark Plug Gap (in) 0.020
Spark Plug Torque (in-lbs) 180
