Snapper SP60V User Manual

22
PARTS LIST
ITEM NO. PART NO. DESCRIPTIONQTY
1
311121519Upper handle assembly1
2 311031519Lower handles 2
3 32910131Nut M10 4
4
3221637Bolt M10x20 4
5 341011179Back panel1
6 311131519Grass Flap1
7
341251179Rear cover1
8 332111179Torsional spring(rear cover)1
9 332021179Axle (rear cover)1
10
3290506Split washer 82
11 342031179Rubber pad (Height adjustment bracket) 2
12 33301151921" Deck1
13
311081179Side discharge door1
14 311091179CBumper assembly1
15 341021179Dash panel1
16
333041519Height adjustment bracket (left) 1
17 322011519Screw 2
18 322021519Screw 8
19
333051519Height adjustment bracket (right) 1
20 3220951Screw 5
21 32204113Screw 6
22
311141519Height adjustment bar assembly1
23 311071505Rear axel 1
24 311071519Rear Wheel2
25
333031179BHeight adjustment link bar 1
26 3220343Nut M62
27 332011179Height adjustment tension spring1
28
311061505front axel1
29 311081519Front Wheel 2
30 33307470Sheeting4
31
32204113Screw 6
32 32202509Screw 2
33 31109151960V power head1
34
32243563Nut 4
35 311151519Blade 1
36 312011519Rear bag1
37
341241179Side discharge chute 1
38 341351179mulch plug1
39 211011331Battery 1
40
211011332Charger 1
3220537
Not for Reproduction
