Snapper SPA521 - Page 35

36" MOWER DECK ASSEMBLY (Fixed Height)
Footnotes:
TP 400-5023-4-CW-N
Manual No. 7006928PRO HYDRO
SERIES 1 & 2
35
Part No Descri
p
tionItem Qt
y
Note
1 7012709 1 RING, 1” External Retaining
2 7013010 1 DECAL, Warning (CPSC Cut Finger)
3 7073647 1 DECAL, Danger, Keep Hands and Feet Away
4 7023735 3 KNOB, Hood (5/16-18 thread)
5 7024156 1 DECAL, Caution- Operator Instruction
6 7027950 1 SPRING, Chute
7 7035710 1 * V-BELT, 36” Deck Drive (Nom. Effective Length: 84.80”)
8 7029277 1 HINGE PIN, Chute
9 7029278 1 SPRING, Idler
10 7076940 3 SCREW, 5/16-18 x 4-1/2” Hex Head Cap, GR 5
11 7091313 1 COTTER PIN, 3/32 x 1”
12 7046580 1 DECAL, SNAPPER Pro w/Trademark
13 7058871 1 DEFLECTOR, 36” ANSI Compliant (Weldment)
14 7034963 1 COVER, 36”
15 7041295 1 PIVOT, Idler Arm (Weldment)
16 7054018 1 ASSEMBLY, Idler Arm, 36”
17 7057736 2 ASSEMBLY, Caster Red w/Gray Wheel
18 7054021 1 ASSEMBLY, 36” Deck, Fixed Height Deck weldment (7044665) plus
4 bushings (7023556)
19 7076998 2 LUBE FITTING, 1/4-28 Straight
20 7091299 5 NUT, 3/8-16 Hex Nyloc
21 7091304 3 BOLT, 3/8-16 x 1” Hex Head Cap, GR 5
22 7091305 1 SCREW, 3/8-16 x 2” Hex Head Cap, GR5
23 7044626 4 BUSHING, Caster
24 7091601 3 NUT, 5/16-18 Hex Flange Lock, GR 5
25 7091528 9 WASHER, 3/8” I.D. Flat
26 7021128 6 SPACER
27 7054011 2 ASSEMBLY, Spindle see Cutter Housing Assembly
page
NOTE: * Part numbers are printed on belts.
