KNOW YOUR STRING TRIMMER (See Figure 1.)
The safe use of this product requires an understanding of the information on
the product and in this operator’s manual as well as a knowledge of the project
you are attempting. Before use of this product, familiarize yourself with all
operating features and safety rules.
1. REAR HANDLE
Ergonomic handle with overmold improves comfort and grip.
2. SAFETY LOCK-OUT TRIGGER
The safety lock-out trigger prevents accidental starting.
3. HIGH/LOW SPEED BUTTON
Set the speed to low for greater runtime and high for quicker cutting.
4. TRIGGER
Activates the string trimmer when pulled.
5. AUXILIARY HANDLE
The string trimmer is equipped with an auxiliary handle for added control and
ease of operation.
6. COUPLER
The coupler connects and locks the two shafts.
7. EDGE GUIDE
8. CUT-OFF BLADE
Adjustable steel blade on the guard keeps the cutting line at the proper
cutting length.
9. GUARD
KNOW YOUR STRING TRIMMER
