ASSEMBLY
12
ATTACHING THE AUXILIARY HANDLE (See Figure 3.)
1. Loosen the four screws (1) in the handle with a philips screwdriver (not included) and
remove the screws from the handle.
1
2
3
2. Attach the auxiliary handle (2) and lower clamp (3) on the shaft.
3. Adjust handle up or down, if necessary, to desired operating position.
4. Tighten the four screws so that the handle cannot be rotated on the shaft.
Fig. 3.1
Fig. 3.2
Fig. 3.3
