PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
1A 770439 TUBE, ASSEMBLY, NA & EU 1
1 ----- TUBE 1
2A 770440 SWITCH, ASSEMBLY, NA & EU 1
3A ----- SWITCH 1
4 ----- SCREW 1
5 ----- WASHER, SPRING 1
6 ----- MAT, FLAT 2
3A 770443 KIT, LEFT HANDLE, NA 1
7A ----- HANDLE, LEFT 1
8A ----- COVER, LEFT DECORATIVE 1
9A ----- BUTTON, PCB 1
10 ----- NUT 1
11 ----- SCREW 3
12 ----- SCREW 7
4 770446 TUBE, CONNECTING 1
17 ----- TUBE, CONNECTING 1
5 770447 MOTOR 1
18 ----- MOTOR 1
19 ----- CUSHIONING 4
6 770448 TUBE, AIR INLET 1
20 ----- TUBE, AIR INLET 1
7A 770449 KIT, INLET GUARD 1
21A ----- GUARD, INLET 1
22 ----- SCREW 4
8A 770450 SWITCH, TRIGGER 1
23A ----- SWITCH, TRIGGER 1
9 770453 KIT, PCB 1
24 ----- WIRE, 25CM 1
25 ----- TUBE, 24CM, HEAT SHRINKABLE 1
26 ----- TERMINAL 1
27 ----- TERMINAL 1
28 ----- INSERT 1
29 -----
PCB 1
30 ----- SWITCH, SPEED 1
10 770454 KIT, BASE SPRING 1
31 ----- BASE, SPRING 1
32 ----- SPRING, BATTERY BOUNCE 2
