PARTS LIST
Item No. Part No. Description QTY
1A 770148 KIT, HOUSING TOP COVER, NA 1
1A1 ----- COVER, TOP 1
1A2 ----- INSERT, TOP COVER 1
1A3 ----- SCREW 5
1A5 ----- SCREW 2
2A 770149 HANDLE, RIGHT 1
3A 770150 KIT, AUXILIARY HANDLE 1
3A1 ----- HANDLE, AUXILIARY 1
3A2 ----- BASE, AUXILIARY HANDLE 1
3A3 ----- SCREW 4
4A 770151 KIT, HARNESS CLAMP 1
4A1 ----- BOLT 1
4A2 ----- SCREW 1
4A3 ----- CLAMP, HARNESS 1
4A4 ----- CLIP, HARNESS 1
5A 770153 SHAFT, BOTTOM 1
6A 770152 KIT, GEAR BOX ASSEMBLY 1
6A1 ----- SCREW 3
6A2 ----- ASSEMBLY, GEAR BOX 1
6A3 ----- SLEEVE, AXLE 1
6A4 ----- BASE, BLADE FIXED 1
7A 770154 PLATE, GRASS PREVENTION 1
8A 770155 HEAD, STRING 1
9A 770156 KIT, GUARD ASSEMBLY 1
9A2 ----- GUARD 1
9A3 ----- BLADE 1
9A4 ----- SCREW 2
9A5 ----- BOLT 4
9A6 ----- BRACKET, GUARD PLATE 1
10A 770157 KIT, TOP SHAFT 1
10A1 ----- SHAFT, TOP 1
10A2 ----- SCREW 1
10A3 ----- CLIP 1
11A 770158 KIT, COUPLING ASSEMBLY 1
11A1 ----- BOLT 1
11A2 ----- SCREW 1
11A3 ----- BOLT 2
