Snapper SXDST82

34
Item No. Part No. Description QTY
11A4 ----- BOLT, T 1
11A5 ----- COUPLING 1
12A 770159 KIT, SWITCH AND LOCK-OUT BUTTON 1
12A1 ----- BUTTON, LOCK-OUT 1
12A2 ----- BUTTON, LOCK-OUT 1
12A3 ----- TRIGGER 1
13A 770160 KIT, LEFT HANDLE 1
13A2 ----- BUTTON, PCB 2
13A3 ----- HOUSING, HANDLE LEFT 1
13A4 ----- SCREW 1
13A5 ----- SCREW 4
14A 770162 KIT, MOTOR AND SWITCH 1
14A1 ----- BRACKET, RUBBER PLATE 2
14A2 ----- MOTOR 1
14A3 ----- CLIP 1
14A4 ----- SCREW 1
14A5 ----- BRACKET , RUBBER PLATE 1
14A6 ----- SCREW 1
14A7 ----- SCREW 1
15A 770163 KIT, LEFT HOUSING 1
15A1 ----- BOLT 1
15A2 ----- BRACKET, RUBBER PLATE 1
15A4 ----- HOUSING, MOTOR 1
15A5 ----- SCREW 1
15A6 ----- SCREW 7
16A 770164 KIT, BATTERY RELEASAE BUTTON 1
16A1 ----- SPRING 1
16A2 ----- PIN 1
16A3 ----- BUTTON, BATTERY RELEASE 1
16A4 ----- BRACKET, PRESS PLATE 1
16A5 ----- SCREW 2
17A 770165 KIT, RIGHT HOUSING 1
17A1 ----- HOUSING, MOTOR 1
17A2 ----- SCREW 1
17A3 ----- BRACKET, RUBBER PLATE 1
18A 770166 KIT, PCB 1
18A1 ----- SPRING 2
18A2 ----- SCREW 2
18A3 ----- SWITCH 1
PARTS LIST
Not for Reproduction
