17
MAINTENANCE
SERVICING
Servicing should be performed by a qualied technician. Replacement parts for this snow shovel must be identical to the
parts that they replace. If repairs are necessary, contact the Toll-Free Helpline, at 1-800-317-7833.
REPLACING THE SCRAPER (See Figures 9-10)
WARNING
In order to avoid serious personal injury, turn the snow shovel off and remove battery before performing any maintenance.
Use only the manufacturer's original replacement parts.
• Place the snow shovel on the ground or on a work bench. Position the snow shovel so that the impeller is facing up.
• Remove the four screws that are located beneath the impeller that secure the scraper to the housing using a phillips
screwdriver. (Fig. 9)
• Remove the scraper, and discard it in the proper manner. (Fig. 10)
• Snap the new scraper into position, and attach it to the snow shovel by reinstalling the four screws.
4 Screws
Scraper
Fig. 9
Scraper
Fig. 10
