Snoppa ATOM - Introduction

ATOM is a foldable three-axis phone gimbal, featuring portable,
lightweight, wired and wireless phone charging, integrated
microphone jack, one-key orientation switch, high payload, long
runtime and so on, which can provide you with brilliant phone
lming experience.
Structural diagram:
[1]
[5]
[9]
[16]
[8]
[7]
[6]
[10]
[21]
[3]
[22]
[2]
[20]
[13]
[12]
[19]
[4]
[15]
[11]
[14]
[17]
[18]
[1] Phone holder
[2] Pan motor
[3] Roll motor
[4] Tilt motor
[5] Mode indicator
[6] Battery indicator
[7] Joystick
[8] Shutter/record key
[9] Menu key
[10] Power
[11] Trigger button
[12] Zoom/Focus slide key
[13] Customizable M key
[14] Customizable back key
[15] Fold key
[16] Strap hole
[17] Gimbal charging port
[18] Phone charging port
[19] ¼ inch threaded hole
[20] Microphone jack
[21] Mic connection port
[22] Motor lock
1
1. Introduction
