Snorkel A38E User Manual

Introduction & Specications
Section
1.2
A38E Work Platform Page 5
1.2 Specications
Table 1-1: Specications
ITEM METRIC IMPERIAL (ANSI)
Duty Cycle
45% of 8 hour shift 45% of 8 hour shift
Platform Size
0.58 m x 1.3 m (inside gaurdrails) 1.77 ft x 4.3 ft (inside gaurdrails)
Max. Platform Capacity
215 kg 475 lbs
Indoors
2 People 2 People
Outdoors
1 People 2 People
Min. Platform Floor Height
13.45 m
11.45 m
0.65 m
44.12 ft
37.56 ft
2.13ft
6.10 m 20.00 ft
Platform Height At
Maximum Outreach
5.40 m 17.72 ft
Stowed Dimensions
Length
Width
Height
4.04 m
1.50 m
2.00 m
13.25 ft
4.92 ft
6.56 ft
Ground Clearance
0.12 m 0.39 ft
Wheel Base x Gauge
2.00 m x 1.27 m 6.56 ft x 4.16 ft
Rotation
362 degrees non-continuous 362 degrees non-continuous
Unloaded Weight
3,795 kg 9,164 lbs
With Load/ Max Weight
4,010 kg 9,639 lbs
Drive Speed Stowed
0 - 4 km/h 0 - 2.49 mph
Drive Speed Elevated
0 - 0.4 km/h 0 - 0.25 mph
Maximum Gradeability
36% 36%
Inside Turning Radius
0.40 m 1.31 ft
Outside Turning Radius
2.40 m 7.87 ft
Power Source
48V DC 4kW, 8 X 6V 210Ah Batteries 48V DC 5.4HP, 8 X 6V 210Ah Batteries
System Voltage Control
12V 12V
Battery Charger
Auto Dual AC input 100-240V ~ 50/60Hz 18A
Output 48V, 25A
(Auto Dual AC input 100-240V ~ 50/60Hz 18A)
Output 48V, 25A
Hydraulic Oil Tank Capacity
25 Litres 6.5 Gallons US
Max. Hydraulic Pressure
145 bar 2105 psi
Hydraulic Oil Grade
ISO #46 ISO #46
Cylinder Types
2 Double Acting Lift Cylinders With Lock
Valves And Manual Emergency Lowering
Facility.
1 Double ActingTelescopic Cylinder
1 Double Acting Plat. Rotate Cylinder
2 Double Acting Lift Cylinders With Lock
Valves And Manual Emergency Lowering
Facility.
1 Double ActingTelescopic Cylinder
1 Double Acting Plat. Rotate Cylinder
Refer to Section 5 of the Service & Parts
Manual
Refer to Section 5 of the Service &
Parts Manual
Control System
One handed Proportional Joystick
Operating Energy Efcient Motor Control
System
One handed Proportional Joystick
Operating Energy Efcient Motor
Control System
Wheels/Tyres
400 mm Diameter Steel Disc Wheel With
Solid All Surface Tyres
15.75 inch Diameter Steel Disc Wheel
With Solid All Surface Tyres
Braking
Automatic Spring Applied Hydraulic
Release
Automatic Spring Applied Hydraulic
Release
Max Noise Level
69.5 dB(A) 69.5 dB(A)

Snorkel A38E Specifications

General

Model	A38E
Power Source	Electric
Battery	48V
Ground Clearance	6 in
Drive Speed	3.5 mph
Tire Type	Solid
Working Height	13.5 m (44 ft)
Platform Capacity	215 kg (475 lbs)
