Snorkel TM12E User Manual

アイテム 部品番号 名前 数量 UOM
- 10001135E TM12EASSEMBLY EA
1 10000001 ASSY,CHASSISTM12 1 EA
2 10000002 ASSY,MASTTM12 1 EA
3 10001108 ASSY,EXTPLATFORMTM12E 1 EA
4 10000072 CYLINDER,LIFT 1 EA
5 6019281 SOLENOIDVALVE 1 EA
6 11700-009 FTNGSTR-06MB-06MFSF5OLO 1 EA
7 6091348 CHECKVALVEPOPPETFLOW
WITH0
1 EA
8 6019289 COIL20VDCHYDRAFORCE
4303620
1 EA
9 10001184 HANDLE,ALUM"T"10-32
THREAD
1 EA
10 11001-008 WASHER1/2SAEFLATASTM 8 EA
11 10908-008 NUT1/2-13UNCHEXLOCKREG 4 EA
12 10004-012 SCREW1/2-13UNCHHCX1-1/2 4 EA
13 10303-004 SCREW1/2SHSHLDRX1/2 2 EA
14 11001-004 WASHER1/4SAEFLATASTM* 10 EA
15 10908-004 NUT1/4-20UNCHEXLOCKREG 5 EA
16 10000-014 SCREW1/4-20UNCHHCX1-3/4 2 EA
17 10000-018 SCREW1/4-20UNCHHCX2-1/4 1 EA
18 10000-007 SCREW1/4-20UNCx7/8HHCG8 2 EA
Not
Shown
10001081 SCREWNAILNO4X1/4L 4 EA
Not
Shown
10001701 KIT,US110VACPLUG 1 EA
TM12E PARTS MANUAL TM12E ASSEMBLY
TM12E ASSEMBLY Mon Feb 15 04:08:52 UTC 2021 2-1
