アイテム 部品番号 名前 数量 UOM
24 10001641 SHLDRBOLT,
M12x30MMxM10x1.75T
2 EA
25 10001401 ASSYTOWKICKLOADCELL 1 EA
26 10001405 PLTPLATFORMMASTCVR
LOADCELL
1 EA
27 11015-007 WASHERM5 6 EA
28 10501-020 BUTTONHEADHEXM5-0.8X
20MM
6 EA
29 11015-008 WASHERM6FLATMETRIC 4 EA
30 10502-016 BUTTONHEADHEXM6-1.0X
16MM
4 EA
31 10001447 ASSYPLATFORMCTRLTM
W/OL
1 EA
32 10404-020 SCREWM8-1.25HHCX20MM
LG
4 EA
33 562386 LiteratureCompartment 1 EA
34 11001-004 WASHER1/4SAEFLATASTM* 4 EA
35 10000231 RIVET,1/4DIA.063-.250THK 4 EA
36 10001701 KIT,US110VACPLUG 1 EA
TM12E PARTS MANUAL LOADCELL ASSEMBLY ANSI CE
LOADCELL ASSEMBLY ANSI CE Mon Feb 15 04:09:21 UTC 2021 2-16
