アイテム 部品番号 名前 数量 UOM
- 10001380F PLATFORMASSEMBLY
LOADCELLNOVEMBER2018
ANDBEFORE
EA
1 10001382 WLDMTPLATFORMLOADCELL 1 EA
2 10001110 WLDMT,PLATFORMEXT
TM12E
1 EA
3 10000250 WLDMT,PLATFORMAXLEREAR
ORG
2 EA
4 1502269 ROLLER,PLATFORMEXTENSION 4 EA
5 10016000 ASSY,EXTENSIONLOCK 2 EA
6 10001131 PLATE,HANDRAILTOPSLIDE 2 EA
7 5569973 SLIDEPAD,STICKONOCTOBER
2017ANDBEFORE
6 EA
8 10001132 TUBE,HANDRAILMID
TELESCOPE
2 EA
9 10001062 PLATFORMKEEPERSPACER
ORG
2 EA
10 10000256 PLATEPLATFORMKEEPER
ORG
2 EA
11 10001220 NUTSERTM8-1.25X3.8GRIP 28 EA
12 11015-010 WASHERM8FLAT 8 EA
13 10404-025 SCREWM8-1.25HHCX25MM
LG
8 EA
14 10001219 NUTSERTM6-1.0X4.2GRIP 10 EA
15 11015-008 WASHERM6FLATMETRIC 6 EA
16 10402-025 BOLTM6-1.0X25MM 6 EA
17 10000499 RIVET,3/16DIA.251-.375THK 8 EA
18 10939-010 LOCKNUTM8 4 EA
19 10504-055 BUTTONHEADHEXM8-1.25X
55MM
2 EA
20 10504-045 BUTTONHEADHEXM8-1.25X
45MM
2 EA
TM12E PARTS MANUAL
PLATFORM ASSEMBLY WITH LOADCELL NOVEMBER 2018 AND BEFORE
PLATFORM ASSEMBLY WITH LOADCELL NOVEMBER 2018 AND BEFORE
Mon Feb 15 04:09:25 UTC 2021 2-21
