Snorkel TM12E - Page 117

アイテム 部品番号 名前 数量 UOM
* 10001380G PLATFORMLOADCELL
ASSEMBLYDECEMBER2018
ANDAFTER
EA
1 10001382 WLDMTPLATFORMLOADCELL 1 EA
2 10001110 WLDMT,PLATFORMEXT
TM12E
1 EA
3 10000250 WLDMT,PLATFORMAXLEREAR
ORG
2 EA
4 1502269 ROLLER,PLATFORMEXTENSION 4 EA
5 10001132 TUBE,HANDRAILMID
TELESCOPE
2 EA
6 10001687 ASSY,FOOTLATCH 1 EA
7 10001697 WLDMT,LHHNDRLTOPSLIDE
TME
1 EA
8 10001698 WLDMT,RHHNDRLTOPSLIDE
TME
1 EA
9 1501583 CLIPHANDLE1.00 2 EA
10 1503079 WLDMT,SLIDEHANDLESHORT 2 EA
11 5563451 PLUGTUBING1.00X.095 4 EA
12 1502834 SLIDEPAD,STICKON
NOVEMBER2017ANDAFTER
2 EA
13 10001220 NUTSERTM8-1.25X3.8GRIP 12 EA
14 11015-010 WASHERM8FLAT 12 EA
15 10404-025 SCREWM8-1.25HHCX25MM
LG
12 EA
16 10939-010 LOCKNUTM8 4 EA
17 10504-060 BUTTONHEADHEXM8-1.25X
60MM
4 EA
18 10504-045 BUTTONHEADHEXM8-1.25X
45MM
2 EA
19 10500-020 BOLTBHCSM4-0.70mmX20
10.9
4 EA
20 5563552 NUTHEXM4X0.7YLZNPLT
GR10.9
4 EA
21 10404-090 SCREW,M8-1.25HHCx90MM
LG
2 EA
TM12E PARTS MANUAL
PLATFORM LOADCELL ASSEMBLY DECEMBER 2018 AND AFTER
