Snorkel TM12E - Page 121

アイテム 部品番号 名前 数量 UOM
- 10001687A FOOTLATCHASSEMBLY EA
1 10001688 WLDMT,LEVERPIVOTBRACKET 1 EA
2 502141-000 STOPLEVER 1 EA
3 009442-003 SPRINGLATCH 1 EA
4 11001-006 WASHER3/8SAE 2 EA
5 10002-010 SCREW3/8-16UNCHHCX1-1/4 1 EA
6 10908-006 NUTHEXESNALOCK.375-16
UNCGR8PLTD
1 EA
TM12E PARTS MANUAL FOOT LATCH ASSEMBLY
FOOT LATCH ASSEMBLY Mon Feb 15 04:09:27 UTC 2021 2-23
