Snorkel TM12E - Page 125

アイテム 部品番号 名前 数量 UOM
22 10504-080 SCREW,M8-1.25BHCSX80MM
LG
8 EA
23 10939-010 LOCKNUTM8 12 EA
24 1502128 PLT,DOORSTOPSHIM 8 EA
25 10001220 NUTSERTM8-1.25X3.8GRIP 12 EA
26 10404-022 BOLTM8-1.25X22MM 12 EA
27 10001219 NUTSERTM6-1.0X4.2GRIP 12 EA
28 11015-008 WASHERM6FLATMETRIC 8 EA
29 10502-016 BUTTONHEADHEXM6-1.0X
16MM
2 EA
30 10001221 WASHERM6FLATFENDER 4 EA
31 10000231 RIVET,1/4DIA.063-.250THK 4 EA
32 10402-025 BOLTM6-1.0X25MM 6 EA
33 10000499 RIVET,3/16DIA.251-.375THK 8 EA
34 10504-045 BUTTONHEADHEXM8-1.25X
45MM
2 EA
35 10504-060 BUTTONHEADHEXM8-1.25X
60MM
2 EA
TM12E PARTS MANUAL PLATFORM EXTENSION ASSEMBLY TM12E
PLATFORM EXTENSION ASSEMBLY TM12E
Mon Feb 15 04:09:28 UTC 2021 2-24
