アイテム 部品番号 名前 数量 UOM
- 10001108E TM12EEXTENSIONPLATFORM
ASSEMBLY
EA
1 10001109 WLDMT,PLATFORMBASE
TM12E
1 EA
2 10001110 WLDMT,PLATFORMEXT
TM12E
1 EA
3 10001113-5 WLDMT,PLATDOORRTTM12E
ORG
1 EA
4 10001112-5 WLDMT,PLATDOORLEFT
TM12ORG
1 EA
5 10001164 PLATE,PLATFORMMASTTOP
COVER
1 EA
6 10001462 WEARPAD,MASTWIDE 2 EA
7 10001468 WEARPAD,MAST,SHORT,
NARROW
2 EA
8 10001374 CONTROLBOXASSY-UPPER 1 EA
9 562386 LiteratureCompartment 1 EA
10 10000250 WLDMT,PLATFORMAXLEREAR
ORG
2 EA
11 1502269 ROLLER,PLATFORMEXTENSION 4 EA
12 10016000 ASSY,EXTENSIONLOCK 2 EA
13 10001131 PLATE,HANDRAILTOPSLIDE 2 EA
14 5569973 SLIDEPAD,STICKONOCTOBER
2017ANDBEFORE
6 EA
15 10001132 TUBE,HANDRAILMID
TELESCOPE
2 EA
16 10001062-5 PLATFORMKEEPERSPACER
ORG
2 EA
17 10000256 PLATEPLATFORMKEEPER
ORG
2 EA
18 5516359 HINGE,SPRING 4 EA
19 1501844 BUMPER,GATES 4 EA
20 11001-005 WASHERFW0.3125 36 EA
21 10000231 RIVET,1/4DIA.063-.250THK 40 EA
TM12E PARTS MANUAL PLATFORM EXTENSION ASSEMBLY TM12E
PLATFORM EXTENSION ASSEMBLY TM12E
Mon Feb 15 04:09:29 UTC 2021 2-25
