アイテム 部品番号 名前 数量 UOM
- 10000001G TM12E(IMPERIAL)CHASSIS
ASSEMBLY
EA
1 10000004 WLDMT,CHASSISTM12 1 EA
2 10000007 WLDMT,POTHOLEBARLF 1 EA
3 10000008 WLDMT,POTHOLEBARRT 1 EA
4 10000009 WLDMT,POTHOLELINK 2 EA
5 10000010 WLDMT,POTHOLEPLUNGER
MT
1 EA
6 10000011 ASSY,POTHOLEPLUNGER 1 EA
7 10000012 CWT,POTHOLE 2 EA
8 41040-000 REARWHEELASSEM 2 EA
9 10000092 ASSY,WHEEL323MM 2 EA
10 10000025-5 WLDMT,BATTERYDOORLF 1 EA
11 10000026-5 WLDMT,BATTERYDOORRT 1 EA
12 10000039 PIN,BATTERYDOOR 2 EA
13 1500948 PLT,TRAYPINKEEPER 2 EA
14 1501420 HINGEBLOCK,LOWER 4 EA
15 13571-000 LATCHPADDLEALLEGIS
LA1004SS
2 EA
16 3050009 BATTERY,6v 4 EA
17 10000151 PLATE,DOORLATCH 2 EA
18 10000152 BRKT,BATTERYBRACE 2 EA
19 10001089 WIRE,LEFTBANKJUMPER 1 EA
20 10001088 WIRE,MAINGROUND 1 EA
21 10001090 WIRE,PGGND 1 EA
22 10001091 WIRE,PGGNDJUMPER 1 EA
23 10001084 WIRE,MAINPOSITIVE 1 EA
24 10001086 WIRE,PGPWRJUMPER 1 EA
25 10001085 WIRE,PGMASTERPWR 1 EA
26 10001087 WIRE,JUMPER 1 EA
TM12E PARTS MANUAL CHASSIS ASSEMBLY TM12E
CHASSIS ASSEMBLY TM12E Mon Feb 15 04:08:54 UTC 2021 2-2
