アイテム 部品番号 名前 数量 UOM
- 10001240D STEPASSEMBLYSEPTEMBER
2017ANDBEFORE
EA
1 10001370 WLDMT,STEP 1 EA
2 10001372 PANEL,STEPCONTROL 1 EA
3 13158-003 SPDT,(MOM-OFF-MOM),MICRO
SW
1 EA
4 13158-005 SPDT,1NT1-6(MOM-OFF),
MICROSW
1 EA
5 3020087 KEYSWITCH 1 EA
- 8030044 REPLACEMENTKEY 1 EA
6 510524-000 PUSH/PULLSWASSYW/NC
CONTACT
1 EA
- 09-1933 CONTACTBLOCK(NC) 1 EA
7 12561-000 RECESSEDOUTLET 1 EA
8 10001218 NUTSERTM5-0.8X3.3GRIP 3 EA
9 11015-007 WASHERM5 3 EA
10 10501-020 BUTTONHEADHEXM5-0.8X
20MM
3 EA
11 10939-006 LOCKNUT,M4 4 EA
12 10420-012 SHCSM4-0.7X12MM 4 EA
13 11015-006 WASHERM4 4 EA
14 10424-012 SHCS,M8-1.25X12mm 4 EA
15 515098-000 CHARGER24vdc,PYLON(SN
01-01412)
1 EA
16 515098-001 WIREASSEM,CHARGERLED,
PYLON(SN01-01412+)
1 EA
17 302829 LIGHTRED24VDCBEZEL
MOUNT
1 EA
18 10001163 HARNESS,TMCHASSISAC 1 EA
TM12E PARTS MANUAL STEP ASSEMBLY OCTOBER 2018 AND BEFORE
STEP ASSEMBLY OCTOBER 2018 AND BEFORE
Mon Feb 15 04:09:39 UTC 2021 4-1
