Snorkel TM12E - Page 19

アイテム 部品番号 名前 数量 UOM
53 11705-001 FITTINGELBOW45-4MBA-
4MFS
1 EA
54 11700-001 FITTINGSTRAIGHT-04MB-
04MFS
1 EA
55 10001572 HYD,POWERUNIT,WUXI,TM,
4L
1 EA
56 3040268 BOOTBTRYCABLEENDBLK 4 EA
57 10000048 PLATE,CHASSISTOPCOVER 1 EA
58 11001-006 WASHER3/8SAE 2 EA
59 10908-006 NUTHEXESNALOCK.375-16
UNCGR8PLTD
1 EA
60 10002-010 SCREW3/8-16UNCHHCX1-1/4 1 EA
61 11015-011 WASHERM10FLATMETRIC 6 EA
62 10405-020 SCREWM10-1.5HHCX20mm 2 EA
63 10501-020 BUTTONHEADHEXM5-0.8X
20MM
2 EA
64 11015-007 WASHERM5 2 EA
65 10303-006 SCREW#10-24UNCSBHCX3/4 2 EA
66 10002-014 SCREW3/8-16UNCHHCX1-3/4 2 EA
67 11001-004 WASHER1/4SAEFLATASTM* 43 EA
68 10000-004 SCREW1/4-20UNCHHCX1/2 17 EA
69 10000080 BEARING,FLANGED.750SHAFT
X
30 EA
70 10000076 PIN,CLEVIS,.750DIAX2.25U 3 EA
71 10000079 RETAININGRING,.750DIA 11 EA
72 11015-012 WASHERM12FLATMETRIC 6 EA
73 10406-020 SCREWM12-1.75HHCX20mm
LG
2 EA
74 11001-005 WASHERFW0.3125 1 EA
75 10001-014 BOLT,5/16-18X1-3/4 1 EA
76 10908-005 NUT5/16-18UNCHEXLOCK
REG
1 EA
77 11363-002 CLAMPFORDIPSTICK3/8LOOP 12 EA
TM12E PARTS MANUAL CHASSIS ASSEMBLY TM12E
CHASSIS ASSEMBLY TM12E Mon Feb 15 04:08:55 UTC 2021 2-2
