Snorkel TM12E - Page 205

アイテム 部品番号 名前 数量 UOM
* 10001447C PLATFORMCONTROLBOXTM
WITHOVERLOADASSEMBLY
OCTOBER2018ANDAFTER
EA
1 10001375 WLDMTPLATFORMCTRLBOX
TM100
1 EA
2 10001570 PLT,BOTTOMPLATCTRLBOX
W/OL
1 EA
3 10001448 HARNESSUPPERCONTROL 1 EA
4 3020047 Switch,Toggle-HoneywellINTI-
3
1 EA
5 3040625 EnclosureFace 1 EA
6 3040624 RecepticleOutlet20AMP 1 EA
7 510542-000 PUSHBUTTONBLACKC/W1
N/OCON
1 EA
8 510524-000 PUSH/PULLSWASSYW/NC
CONTACT
1 EA
9 302829 LIGHTRED24VDCBEZEL
MOUNT
2 EA
10 13468-01 Trionics-LoadCellInterface 1 EA
11 512459-016 BLTHEXHDM4X0.7X16MM
DIN9338.8ZP
4 EA
12 5560067 NUTSPEEDUTHREADEDM6 4 EA
13 058491-030 BOLTHEXSETSCREWDIN933
M6X30MM8.8ZP
4 EA
14 056066-004 NUTNYLOCKDIN985M48.0ZP 2 EA
15 5563181 HHCSM4X0.7X30G8.8DIN
931
2 EA
16 1501158 PLACPLATFMCONTBOX 1 EA
17 1501159 PLACPLATFMCONTE-
STOP/HORN
1 EA
18 1501359 PLACLIFT/DRIVE 1 EA
19 3028933 Joystick-IAxis,DeadmanGuard 1 EA
TM12E PARTS MANUAL
PLATFORM CONTROL BOX TM WITH OVERLOAD ASSEMBLY OCTOBER 2017 through FEBRUARY 2019
PLATFORM CONTROL BOX TM WITH OVERLOAD ASSEMBLY OCTOBER 2017 through FEBRUARY 2019
