アイテム 部品番号 名前 数量 UOM
- 10001631B PLATFORMCONTROLBOX
ASSEMBLYCE
EA
1 10001375 WLDMTPLATFORMCTRLBOX
TM100
1 EA
2 10001570 PLT,BOTTOMPLATCTRLBOX
W/OL
1 EA
Not
Shown
10001448 HARNESSUPPERCONTROL 1 EA
4 3020047 Switch,Toggle-HoneywellINTI-
3
1 EA
5 510542-000 PUSHBUTTONBLACKC/W1
N/OCON
1 EA
6 302829 LIGHTRED24VDCBEZEL
MOUNT
2 EA
7 13468-01 Trionics-LoadCellInterface 1 EA
8 3028933 Joystick-IAxis,DeadmanGuard 1 EA
9 3028810 PUSH/PULLEMERGENCYSTOP 1 EA
10 512459-016 BLTHEXHDM4X0.7X16MM
DIN9338.8ZP
6 EA
11 5560067 NUTSPEEDUTHREADEDM6 4 EA
12 058491-030 BOLTHEXSETSCREWDIN933
M6X30MM8.8ZP
4 EA
13 056066-004 NUTNYLOCKDIN985M48.0ZP 4 EA
14 5563181 HHCSM4X0.7X30G8.8DIN
931
2 EA
15 3040015 HOLEPLUG.50 1 EA
16 1501158 PLACPLATFMCONTBOX 1 EA
17 1501159 PLACPLATFMCONTE-
STOP/HORN
1 EA
18 1501359 PLACLIFT/DRIVE 1 EA
19 1501688 PLT,COVEROUTLET 1 EA
TM12E PARTS MANUAL PLATFORM CONTROL BOX CE
PLATFORM CONTROL BOX CE Mon Feb 15 04:09:49 UTC 2021 4-22
