アイテム 部品番号 名前 数量 UOM
78 10908-004 NUT1/4-20UNCHEXLOCKREG 12 EA
79 10000-010 SCREW1/4-20UNCHHCX1-1/4 8 EA
80 10000-020 SCREW1/4-20UNCHHCX2-1/2 2 EA
81 10000486 BOLT,WHEELLUGM12-1.5X
21MM
10 EA
82 10054-005 SHCR1/4-20X.625 8 EA
83 10000013 BUSHING,POTHOLEBAR 4 EA
84 10000268 BUSHING,POTHOLEBAR 2 EA
85 10000014 SLEEVE,POTHOLEPLUNGER 1 EA
86 10001102 SPRING1ODX.5IDX6MCM 1 EA
87 10000077 PIN,CLEVIS,.750DIAX3.25U 2 EA
88 10000078 PIN,CLEVIS,.750DIAX1.75U 2 EA
89 10001478 SHIM,0.060X3/4IDX1.00OD 8 EA
90 10405-012 BOLT,HHCS,M10-1.50mmx12
CLASS10.9,DIN933,PLTD
4 EA
91 10800-008 BLT,1/4-20UNCCARRAGEX1 2 EA
92 11111-001 RIVET,3/16"DIAX0.126"-0.25" 8 EA
93 2500812 BEARING 4 EA
94 10001059 SHIM.032THICK5/8ID.875
MC
4 EA
95 10000155 BUMPER,RUBBER 2 EA
96 10001630 HARNESS,CHASSIS,TM 1 EA
97 10001211 WIRE,DRIVEARMPWR 2 EA
98 10001212 WIRE,DRIVEARMNEG 2 EA
99 10001213 HARNESS,DRIVEFIELD 1 EA
100 10001214 WIRE,HPUPOS 1 EA
101 10001215 WIRE,HPUNEG 1 EA
TM12E PARTS MANUAL CHASSIS ASSEMBLY TM12E
CHASSIS ASSEMBLY TM12E Mon Feb 15 04:08:56 UTC 2021 2-2
