アイテム 部品番号 名前 数量 UOM
- 10001374D UPPERCONTROLBOX
ASSEMBLY
EA
1 10001375 WLDMTPLATFORMCTRLBOX
TM100
1 EA
2 1501116 PLTBOTTOMPLATFORM
CONTROLBOX
1 EA
3 3028810 PUSH/PULLEMERGENCYSTOP 1 EA
4 3020047 Switch,Toggle-HoneywellINTI-
3
1 EA
5 510542-000 PUSHBUTTONBLACKC/W1
N/OCON
1 EA
6 302829 LIGHTRED24VDCBEZEL
MOUNT
1 EA
Not
Shown
10001101 HARNESS,UPPERCTRL 1 EA
8 3040624 RecepticleOutlet20AMP 1 EA
9 3040625 EnclosureFace 1 EA
10 3028933 Joystick-IAxis,DeadmanGuard 1 EA
11 1502308 HARNESS110VJUMPER 1 EA
12 5560067 NUTSPEEDUTHREADEDM6 4 EA
13 058491-030 BOLTHEXSETSCREWDIN933
M6X30MM8.8ZP
4 EA
14 512459-016 BLTHEXHDM4X0.7X16MM
DIN9338.8ZP
4 EA
15 3040015 HOLEPLUG.50 1 EA
16 1501158 PLACPLATFMCONTBOX 1 EA
17 1501159 PLACPLATFMCONTE-
STOP/HORN
1 EA
18 1501359 PLACLIFT/DRIVE 1 EA
TM12E PARTS MANUAL UPPER CONTROL BOX ASSEMBLY
UPPER CONTROL BOX ASSEMBLY
Mon Feb 15 04:09:50 UTC 2021 4-23
