Snorkel TM12E - Page 29

アイテム 部品番号 名前 数量 UOM
28 010154-000 COVERBATTERY 7 EA
29 10001240 ASSYSTEPPYLON 1 EA
30 10001632 ASSY,LWRCTRLPNL,NONOL 1 EA
31 10000038 PLATE,TOEKICK 1 EA
32 10000040 ASSY,HUB 2 EA
33 10000047 PLATE,STEERLINK 2 EA
34 2580430 THRUSTBRG,80mmID
100mmOD3mmTHK
2 EA
35 10000073 CYLINDER,STEER 1 EA
36 10000157 PIN,STEERCYLCENTER 2 EA
37 10000159 PLT,STEERPINKEEPER 1 EA
38 10000452 WLDMT,TM12STEER 1 EA
39 10001105 WELD,STEERPIN 4 EA
40 3087803 EZCalPanel-Trionics 1 EA
41 10001629 COMPUTER,TS100 2 EA
42 13161-000 SWITCH 1 EA
43 13162-000 SWITCHLOCK 1 EA
44 3028844 IFS241(IFMPROXY) 3 EA
45 13201-000 RELAYSOLENOIDNOSPST
24VDC
1 EA
46 3049978 ALARMBEEPING 1 EA
47 10001095 HORN 1 EA
48 10001096 PLATE,BUSSBAR 1 EA
49 467966 STATICSTRAPRUBBERGRD
30in
1 EA
50 10001363 KIT,HOSETM100 1 EA
51 11702-006 FITTINGELBOW90-06MBA-
06MFS
1 EA
52 11702-002 FTNGELBOW90-06MBA-
04MFS
2 EA
53 11705-001 FITTINGELBOW45-4MBA-
4MFS
1 EA
TM12E PARTS MANUAL TM12E CHASSIS ASSEMBLY
TM12E CHASSIS ASSEMBLY Mon Feb 15 04:08:59 UTC 2021 2-3
