アイテム 部品番号 名前 数量 UOM
- 10001419F TM12ECHASSISASSEMBLY
LOADCELL
EA
1 10001189 WLDMTCHASSISTM12E 1 EA
2 10000007 WLDMT,POTHOLEBARLF 1 EA
3 10000008 WLDMT,POTHOLEBARRT 1 EA
4 10000009 WLDMT,POTHOLELINK 2 EA
5 10000010 WLDMT,POTHOLEPLUNGER
MT
1 EA
6 10000011 ASSY,POTHOLEPLUNGER 1 EA
7 10000213 COUNTERWEIGHT,CAST 2 EA
8 10000013 BUSHING,POTHOLEBAR 4 EA
9 10000268 BUSHING,POTHOLEBAR 2 EA
10 10000014 SLEEVE,POTHOLEPLUNGER 1 EA
11 10001102 SPRING1ODX.5IDX6MCM 1 EA
12 10000076 PIN,CLEVIS,.750DIAX2.25U 3 EA
13 10000077 PIN,CLEVIS,.750DIAX3.25U 2 EA
14 10000078 PIN,CLEVIS,.750DIAX1.75U 2 EA
15 10000079 RETAININGRING,.750DIA 11 EA
16 10000080 BEARING,FLANGED.750SHAFT
X
30 EA
17 41040-000 REARWHEELASSEM 2 EA
18 10000092 ASSY,WHEEL323MM 2 EA
19 10001196 WLDMTBATTERYDOORLF 1 EA
20 10001197 WLDMTBATTERYDOORRT 1 EA
21 10000039 PIN,BATTERYDOOR 2 EA
22 1500948 PLT,TRAYPINKEEPER 2 EA
23 1501420 HINGEBLOCK,LOWER 4 EA
24 13571-000 LATCHPADDLEALLEGIS
LA1004SS
2 EA
25 3050009 BATTERY,6v 4 EA
26 10000151 PLATE,DOORLATCH 2 EA
TM12E PARTS MANUAL TM12E CHASSIS ASSEMBLY LOADCELL
TM12E CHASSIS ASSEMBLY LOADCELL
Mon Feb 15 04:09:03 UTC 2021 2-4
