Snorkel TM12E - Page 41

アイテム 部品番号 名前 数量 UOM
27 10000152 BRKT,BATTERYBRACE 2 EA
28 10001089 WIRE,LEFTBANKJUMPER 1 EA
29 10001088 WIRE,MAINGROUND 1 EA
30 10001090 WIRE,PGGND 1 EA
31 10001091 WIRE,PGGNDJUMPER 1 EA
32 10001084 WIRE,MAINPOSITIVE 1 EA
33 10001086 WIRE,PGPWRJUMPER 1 EA
34 10001085 WIRE,PGMASTERPWR 1 EA
35 10001087 WIRE,JUMPER 1 EA
36 3014756 WIRE2R313R3137BLACK
FUSED
1 EA
- 446076 FUSE,250AMP,REPLACEMENT 1 EA
37 010154-000 COVERBATTERY 7 EA
38 10001240 ASSYSTEPPYLON 1 EA
39 10000038 PLATE,TOEKICK 1 EA
40 10001203 TM12HUBASSY 2 EA
41 10000333 STEERINGLINK,CAST 2 EA
42 2580430 THRUSTBRG,80mmID
100mmOD3mmTHK
2 EA
43 10000073 CYLINDER,STEER 1 EA
44 10000337 PIN,STEERCYLTEE 1 EA
45 10000157 PIN,STEERCYLCENTER 1 EA
46 10000159 PLT,STEERPINKEEPER 1 EA
47 10000330 STEERINGTEE,CAST 1 EA
48 10001105 WELD,STEERPIN 4 EA
49 3087803 EZCalPanel-Trionics 1 EA
50 10001629 COMPUTER,TS100 2 EA
51 13161-000 SWITCH 1 EA
52 13162-000 SWITCHLOCK 1 EA
53 3028844 IFS241(IFMPROXY) 3 EA
TM12E PARTS MANUAL TM12E CHASSIS ASSEMBLY LOADCELL
TM12E CHASSIS ASSEMBLY LOADCELL
Mon Feb 15 04:09:03 UTC 2021 2-4
