Snorkel TM12E - Page 45

アイテム 部品番号 名前 数量 UOM
76 10404-040 SCREW,M8-1/25HHCX40MM
LG
1 EA
77 10939-010 LOCKNUTM8 1 EA
78 11363-002 CLAMPFORDIPSTICK3/8LOOP 12 EA
79 10939-008 LOCKNUTM6 12 EA
80 10402-035 SCREWM6X1.00HHCX35MM
LG
6 EA
81 10402-055 SCREW,M6-1.00HHCX55MM
LG
2 EA
82 10402-060 SCREW,M6-1.00HHCX60MM
LG
2 EA
83 10000486 BOLT,WHEELLUGM12-1.5X
21MM
10 EA
84 10422-016 SCREW,M6-1.0SHCSX16MM 8 EA
85 10001478 SHIM,0.060X3/4IDX1.00OD 8 EA
86 10405-012 BOLT,HHCS,M10-1.50mmx12
CLASS10.9,DIN933,PLTD
4 EA
87 10001217 BOLTM6-1.0X25MMCARRIAGE 2 EA
88 11111-001 RIVET,3/16"DIAX0.126"-0.25" 8 EA
89 2500812 BEARING 4 EA
90 10001059 SHIM.032THICK5/8ID.875
MC
4 EA
91 10000155 BUMPER,RUBBER 2 EA
92 10000048 PLATE,CHASSISTOPCOVER 1 EA
93 10001633 ASSY,LWRCTRLPNL,W/OL 1 EA
94 10001211 WIRE,DRIVEARMPWR 2 EA
95 10001212 WIRE,DRIVEARMNEG 2 EA
96 10001213 HARNESS,DRIVEFIELD 1 EA
97 10001214 WIRE,HPUPOS 1 EA
98 10001215 WIRE,HPUNEG 1 EA
99 1610015-000 GUARDPROTECTIVEHEAT
SHRINK(NOTSHOWN)
1 EA
TM12E PARTS MANUAL TM12E CHASSIS ASSEMBLY LOADCELL
TM12E CHASSIS ASSEMBLY LOADCELL
Mon Feb 15 04:09:05 UTC 2021 2-4
