アイテム 部品番号 名前 数量 UOM
76 10402-016 SCREWM6-1.00HHCX16MM
LG
8 EA
77 10000486 BOLT,WHEELLUGM12-1.5X
21MM
10 EA
78 10401-020 BOLTM5-0.80X20MM 4 EA
79 058491-012 BLTHEXHDM6-1.0X12MM
DIN933GR8.8ZP
2 EA
80 10001478 SHIM,0.060X3/4IDX1.00OD 8 EA
81 10807-025 BOLTM6-1.0X25MM 2 EA
82 11111-001 RIVET,3/16"DIAX0.126"-0.25" 8 EA
83 2500812 BEARING 4 EA
84 10001059 SHIM.032THICK5/8ID.875
MC
4 EA
85 10000155 BUMPER,RUBBER 2 EA
86 10000048 PLATE,CHASSISTOPCOVER 1 EA
87 10001089 WIRE,LEFTBANKJUMPER 2 EA
88 1610017-000 HARNESS,TM,SEM300 1 EA
89 1610019-007 CABLE,CONTACTORTOFUSE 1 EA
90 1610018-062 JUMPER,LEFTTORIGHTBANK 1 EA
91 1610019-032 CABLE,BAT+TOFUSE 1 EA
92 1610020-010 CABLE,DISCONTOSEM300 1 EA
93 1610021-016 CABLE,CONTACTORTOSEM300 1 EA
94 1610022-039 CABLE,HPU 2 EA
95 1610023-060 CABLE,MOTORGND 2 EA
96 1610024-060 CABLE,CONTACTORTOMOTOR 2 EA
97 1610018-039 CABLE,BAT-TODISCON 1 EA
98 1610025-000 HARNESS,MOTORCONTROL 1 EA
99 5563554 NUTHEXM6X1YLZNPLT
GR10.9
1 EA
100 10405-020 SCREWM10-1.5HHCX20mm 2 EA
101 10405-016 SCREWM10-1.5HHCX16mm
LG
4 EA
TM12E PARTS MANUAL
CHASSIS TM SEM300 TM SEM300-11-XXXXXX AND AFTER
CHASSIS TM SEM300 TM SEM300-11-XXXXXX AND AFTER
Mon Feb 15 04:09:09 UTC 2021 2-5
