アイテム 部品番号 名前 数量 UOM
- 10000040A HUBASSEMBLY EA
1 10000041 WLDMT,HUBMNT 1 EA
2 10000162 24vDRIVE(HUB,MTR,BRAKE)
MF
1 EA
3 10000092 ASSY,WHEEL323MM 1 EA
4 11001-006 WASHER3/8SAE 6 EA
5 10002-008 SCREW3/8-16UNCHHCX1 6 EA
6 10000486 BOLT,WHEELLUGM12-1.5X
21MM
5 EA
7 2509820 BRG75mmID80mmOD40mmL 2 EA
TM12E PARTS MANUAL HUB ASSEMBLY
HUB ASSEMBLY Mon Feb 15 04:09:13 UTC 2021 2-10
