Snorkel TM12E - Page 98

アイテム 部品番号 名前 数量 UOM
- 10001378J LOADCELLASSEMBLYANSICE EA
1 10001419 ASSYCHASSISTM12E
LOADCELL
1 EA
2 10000072 CYLINDER,LIFT 1 EA
3 6091348 CHECKVALVEPOPPETFLOW
WITH0
1 EA
4 6019289 COIL20VDCHYDRAFORCE
4303620
1 EA
5 11700-009 FTNGSTR-06MB-06MFSF5OLO 1 EA
6 6019281 SOLENOIDVALVE 1 EA
7 10001184 HANDLE,ALUM"T"10-32
THREAD
1 EA
8 10303-004 SCREW1/2SHSHLDRX1/2 2 EA
9 11015-012 WASHERM12FLATMETRIC 12 EA
10 10939-012 NUTM12-1.75REGHEX
LOCK*****
8 EA
11 10406-040 SCREWM12-1.75HHCX40MM
LG
6 EA
12 10001379 ASSYTM12EMAST 1 EA
13 10939-008 LOCKNUTM6 3 EA
14 10402-040 BOLTHHCSM6-1.00MMX40
CLASS10.9ISO4017DIN933
PLTD
2 EA
15 10402-050 BOLTM6-1.0X50MM 1 EA
16 10001380 ASSYPLATFORMLOADCELL 1 EA
17 10001644 ASSY,BEARINGMT,LOADCELL 4 EA
18 11015-010 WASHERM8FLAT 33 EA
19 10404-025 SCREWM8-1.25HHCX25MM
LG
29 EA
20 10001625 PLT,LOADCELLUPPERMT 1 EA
21 10001614 LOADCELL,500KG 1 EA
22 10001640 RODEND,M12,SPHERICALX
12MM
2 EA
23 10001662 HARNESS,LOADCELL 1 EA
TM12E PARTS MANUAL LOADCELL ASSEMBLY ANSI CE
LOADCELL ASSEMBLY ANSI CE Mon Feb 15 04:09:21 UTC 2021 2-16
