#57030OPERATOR’SMANUAL 8
Control Cable Attachment (Fig. 6)
Securethecontrolcabletotheframewithprovidedclips(Fig.6).
Chute Rotation Handle Attachment (Fig. 7–9)
1. Assembletherotationchutebyttingthehandleintothe
rotationpiece.Securewithboltandwasher(Fig.7).
2. Slidetheendofthechuterotationhandlethroughthe
holeonthechutebracketnearthesnowoutputport
(Fig.8).Linethespiralofthehandleupwiththe
groovesinthesnowoutputport.
3. Placethewasheronthechuterotationhandlethen
insertthecotterpinthroughtheendofthechute
rotationhandlenearthechute.Bendtheendsofthe
pintoholdthepininplace.
4. Placetheeyeboltonthechuterotationhandleinto
theholelocatedhalfwayupthelefthandle.Secure
withcuppedwasherandnut(Fig9).
Handle
Fig.7
Piece
Groves
Handle
Piece
Enlarged
View
Fig.9
Fig.8
Fig.6
Clip
Hole
Chute
Rotation
Handle
Left
Handle
Chute
Rotation
Handle
