Snow Devil 57030 - Assembly Instructions

#57030OPERATOR’SMANUAL 7
ASSEMBLY INSTRUCTIONS
YourSnowThrowerwillrequiresomeassembling.
Pleasecompletethefollowingstepsbeforeusing
yourSnowThrower.Foreasyassembly,
werecommendattachingthecomponentsinthe
orderlistedinthismanual.
Ifyouareunsureabouthowtoperformanyofthe
stepspleasecall1-800-232-1195,M–8–5(CST)
forcustomerservice.
Chute Assembly (Fig. 2 & 3)
1. InsertthechutetothesnowoutputportonyourSnow
Thrower(Fig.2).
2. Attachthechutetothesnowoutputportusingthe
boltandwasher(Fig.3).
Handle Assembly (Fig. 4 & 5)
1. AttachthelowerhandletoyourSnowThrowerusing
four(4)bolts(Fig.4).Eachsidewillrequiretwo(2)bolts.
2. Attachedtheupperhandletothelowerhandleusing
four(4)knobsandbolts(Fig.5).
Fig.3
Fig.2
Fig.4
Fig.5
Chute
Snow
Output
Port
Bolt&
Washer
Bolts
Knob
Bolt
