Snow Devil WSE2013 - Parts List

090612
15
ENGLISH
PARTS LIST
Please refer to the schematic drawing on the pages following.
N
O.
DESCRIPTION QTY.
1 Screw 3
2 Left switch bracket 1
3 Switch lever 2
4 Spring 2
5 Right switch bracket 1
6 Screw 5
7 Switch socket housing 1
8 Plug pin 1
9 Screw 2
10 Screw 2
11 Switch bar 1
12 Switch 1
13 Switch button 1
14 Switch button spring 1
15 Cable protector 1
16 Cable clip 3
17 Chute direction handle 1
18 Screw 2
19 Nut 2
20 Knob 2
21 Pin 1
22 Upper chute 1
23 Bolt 2
24 Main chute 1
25 Rivet 3
26 Washer 3
27 Lower Chute 1
28 Screw 1
28A Washer 1
29 Rubber stopper 1
30 Chute base cover 1
31 Steel ball 1
32 Spring 1
33 Bafe 1
34 Screw 3
35 Chute retention plate 2
36 Screw 3
37 Screw 3
38 Side cover (right) 1
39 Bolt 3
40 Bearing seat 2
41 Bearing 2
42 Auger xing plate 2
43 Welded auger assy. 1
44 Auger rubber (left) 2
45 Auger rubber (right) 2
N
O.
DESCRIPTION QTY.
46 Snow scraping rubber (small) 2
47 Washer 12
48 Bolt 4
49 Bolt 8
50 Nut 12
51 Washer 8
52 Screw 3
53 Scraper 1
54 Bolt 3
54A Spring washer 6
55 Big pulley separator 1
56 Big pulley 1
57 Nut 1
58 Left guard 1
58A Screw 4
58B Right guard 1
59 Housing 1
60 Belt 1
61 Left side cover 1
62 Washer 3
63 Screw 3
64 Gear cover 1
65 Oil gasket 1
66 Screw 1
67 Washer 2
68 Screw 3
69 Spring 1
70 Screw 1
71 Motor bracket 1
72 Screw 2
73 Support vent 1
74 Overload protector 1
75 Screw 1
76 Screw 6
77 Inner chute deector 1
78 Carbon brush cover 2
79 Brush holder 2
80 Carbon brush 2
81 Clamp 2
82 Screw 4
83 Motor mount rear 1
84 Vibration dampers 4
85 Motor clamp 1
86 Screw 4
87 Label 1
88 Back cover 1
N
O.
DESCRIPTION QTY.
89 Cable anchor 1
90 Screw 6
91 Screw 6
92 Washer 3
93 Stator 1
94 Plunger 1
95 Bearing 608Z 1
96 Rotor 1
97 Motor mount front 1
98 Bearing 6001Z 1
99 Screw 2
99A Washer 2
99B M4 washer 2
100 Small gear 1
100A Washer 1
101 Screw 4
102 Nut 1
103 Screw 4
104 Bearing 6201Z 1
105 Ring 1
106 Large gear 1
107 Woodruff key 1
108 Output shaft 1
109 Bearing 1
110 Small pulley separator 1
110A Small pulley 1
111 Belt tension support 1
112 Washer 8
113 Screw 8
114 Bearing 1
115 Belt tensioner 1
116 Washer 1
117 Screw 1
118 Ring 2
119 Axle cover 2
120 External circlip 2
121 Axle 1
122 Screw 2
123 Wheel bracket (left) 1
124 Wheel bracket (right) 1
125 Screw 4
126 Nut 4
127 Washer 1
128 Wheel 2
129 Handle tubing lower section 1
130 T-bolt 2
