socomec DIRIS Digiware M-70 - Page 53

53EN
DIRIS Digiware M-50 & M-70 - 548751B - SOCOMEC
30 PowerRActiveQ2 Q2 Reactive
Power
VAr Signed
• • • • •
31
PowerRActiveQ3 Q3 Reactive
Power
VAr Signed
• • • • •
32
PowerApparentS1 S1 Apparent
Power
VA Unsigned
• • • • •
33
PowerApparentS2 S2 Apparent
Power
VA Unsigned
• • • • •
34
PowerApparentS3 S3 Apparent
Power
VA Unsigned
• • • • •
35
PowerFactorPF1 PF1 Power
Factor
- Signed
• • • • •
36
PowerFactorTypeSPF1 sPF1 Power
Factor Type
- Unsigned
• • • • •
37
PowerFactorPF2 PF2 Power
Factor
- Signed
• • • • •
38
PowerFactorTypeSPF2 sPF1 Power
Factor Type
- Unsigned
• • • • •
39
PowerFactorPF3 PF3 Power
Factor
- Signed
• • • • •
40
PowerFactorTypeSPF3 sPF1 Power
Factor Type
- Unsigned
• • • • •
41 LoadCurve_
P+
Load Curve
Positive Active
Power
W
Unsigned
• •
42
LoadCurve_P- Load Curve
Negative Active
Power
W Unsigned
• •
43 LoadCurve_
Q+
Load Curve
Positive Reactive
Power
VAr
Unsigned
• •
44
LoadCurve_Q- Load Curve
Negative
Reactive Power
VAr Unsigned
• •
45 LoadCurve_S Load Curve
Apparent Power
VA
Unsigned
• •
46 THD_I1 THD I1 %
Unsigned
• • • •
47 THD_I2 THD I2 %
Unsigned
• • • •
48 THD_I3 THD I3 %
Unsigned
• • • •
49 THD_In THD In %
Unsigned
• • • •
50 THD_V1 THD V1 %
Unsigned
• • • •
51 THD_V2 THD V2 %
Unsigned
• • • •
52 THD_V3 THD V3 %
Unsigned
• • • •
53 THD_U12 THD U12 %
Unsigned
• • • •
54 THD_U23 THD U23 %
Unsigned
• • • •
55 THD_U31 THD U31 %
Unsigned
• • • •
56 A+ Positive Active
Energy
Wh
Unsigned
• • •
57 A- Negative Active
Energy
Wh
Unsigned
• • •
58 ER+ Positive Reactive
Energy
VArh Unsigned
• • • •
59 ER- Negative
Reactive Energy
VArh Unsigned
• • • •
60 ES Apparent Energy VAh
Unsigned
• • •
61 Mff Multifluid feeder -
Signed
• • •
